LSINFO: Series 60 Ratchet, Pivoting Low Lead
Tuotenumero: RF62174
•Unrivalled 20:1 holding power
• Dual sided On-Off switch
• Ability to operate On/Off switch under load
• Low friction ball bearing system
• Lightweight
• Cheek cut-outs for easy bearing maintenance
The patented extruded hole design, in conjunction with the groove profile of the sheave, provides a more powerful grip than conventional designs – up to 20:1 holding power. Unrivalled low weight is achieved by the use of a Torlon® ratchet pawl, high grade machined alloy sheave and black Acetal hubs and bearings. On-Off switching knob is fitted to both sides of the swivel blocks (one can be removed if desired). Ratchet blocks can be disassembled for sheave replacement with RF62000.
Mainsheet on powerful dinghies and skiffs
Series 60 mainsheet systems on sportsboats using RF7 mainsheet swivel units
Control line applications on larger yachts
Spinnaker sheets on sportsboats and small keel boats (lateral lead blocks)
Sheave Ø 60 mm
Max. Rope Ø 10 mm
Max. Cable Ø – mm
M.W.L. 250 kg
B. L. 1370 kg
Weight 147 g
